APR Roll-Control Lowering Springs - MK8 Golf R - SUS00017

Coil Spring Lowering Kit

SUS00017
Fits 2022-2024 Volkswagen Golf R

Note: For maximum handling, performance, and comfort, combine with APR Bumpstops (SUS00025). All center of wheel to fender (CF) measurements were recorded on our in-house US Spec 2022 MK8 Golf R (DCC) test vehicles and may vary slightly from vehicle to vehicle. Lastly, while this system was designed specifically for the US Spec 2022 MK8 Golf R, it will fit other similar platform vehicles.

Pricing: $286.00

Qty:
Free Shipping

Description

APR Roll-Control Lowering Springs greatly improve the looks and handling of your Volkswagen MK8 Golf R without greatly sacrificing comfort or your wallet! Designed for use with DCC or Non-DCC dampers, our performance lowering springs are a direct plug-and-play upgrade that offer a lower center of gravity and increased spring rates to reduce body roll.

  • 365 mm (OEM) vs 344 mm (APR) or a 21 mm reduction in CF Height
  • 220 lbs/in (OEM) vs 319 lbs/in (APR) or a 45% increase in Spring Rate
  • US 2022 MK8 Golf R (DCC) Rear:
  • 367 mm (OEM) vs 343 mm (APR) or a 24 mm reduction in CF Height
  • 278 lbs/in (OEM) vs 448 lbs/in (APR) or a 61% increase in Spring Rate
  • Many lowering springs on the market today simply lower your vehicle and give a false sense of improvement by feeling overly stiff. We took a different approach with our design. We extensively track and street tested several iterations to deliver a system that not only makes your MK8 Golf R look great, but does so while delivering a comfortable experience that doesn't constantly crash and bottom out the dampers. Through a proper ride height configuration, we're able to greatly increase spring rates for improved handling, but do so without leaving the ride harsh, bouncy, and uncomfortable. Your MK8 Golf R will be planted with a minimal impact on comfort. It's a system you'll love the second you're behind the wheel!
  • These springs were designed in house and manufactured in the USA using a premium high tensile chrome silicon steel for excellent resilience against sagging and failure for years to come. Each spring comes powder coated in our signature red color, further protecting the spring from the elements. The front and rear springs are a dual rate spring that will operate as a single rate, linear spring, under normal loaded driving situations. All center of wheel to fender (CF) measurements were recorded on our in-house US Spec 2022 MK8 Golf R (DCC) test vehicles and may vary slightly from vehicle to vehicle. Lastly, while this system was designed specifically for the MK8 Golf R, it will fit other similar platform vehicles.
  • Specifications:
  • US 2022 MK8 Golf R (DCC) Front:

    • Lowers 21 mm or .83 in Front / 24 mm or .94 in Rear (DCC)
    • Improves handling
    • Does not easily bottom out dampers
    • Designed for use with DCC and Non-DCC OEM dampers
    • Direct plug-and-play
    • Made from a high tensile chrome silicon steel that resists sagging and failure
    • Powder coated red finish protects springs from corrosion
    • Made in the USA
    • Increases Spring Rate 45% or +99 lbs/in at 319 lbs/in Front / 61% or +170 lbs/in at 448 lbs/in Rear (DCC)
    • Dual Rate Spring (183 lbs/in to 319 lbs/in Front)
    • Dual Rate Spring (327 lbs/in to 448 lbs/in Rear)
    • Operates as a single rate “linear” spring during loaded usage
    • Greatly improves vehicles stance and appearance
    • Remains comfortable on the street
    • Lowers the vehicle’s center of gravity
    • Reduces body roll
  • Details

    Categories

    Shipping Information

    • Item Requires Shipping
    • 24.6 lbs.
    • W14.4000” x H8.5000” x L23.8000”
    • Free Shipping
