TURBO ENGINEERS TTE800 UPGRADE TURBOCHARGERS FOR PORSCHE 993 / 996

PORSCHE PERFORMANCE PARTS: TURBO ENGINEERS TTE800 UPGRADE TURBOCHARGERS FOR PORSCHE 993 / 996 (NEW)

Product Features:

Introducing the TTE800 upgrade performance turbochargers based on the original K24 turbochargers to new higher output specification. Offering an upgrade to over 800PS.

• Original BorgWarner turbocharger as the base part
• TTE Billet geometry compressor 54.5MM inlet
• TTE 9 Blade High-Flow Low-Mass turbine
• TTE Upgrade bearing pack
• 800PS+ Capable on 102Ron
• Single parts finely balanced then components assembled and core high-speed VSR balanced
• Supplied with a balance test result document
• Proven TheTurboEngineers quality
• Made in Germany

At the core of the TTE800 upgrade stage is a much larger TTE compressor wheel, chosen because it is highly efficient and creates an extremely high flow for comparative size. Re-Profiled compressor cover to optimized tolerance to ensure maximum compressor efficiency is given.

TTE uses a CNC machine to mill the exhaust turbine housing to accept a larger 9 blade turbine and shaft. Special profile 360 deg high-performance motorsport journal bearing is fitted, to remain durable at higher loads with no loss in transient response. The actuator used is sprung OE unit set at 0.8bar crack pressure(1.0bar if wanted)

Precisely balancing turbochargers is a key critical factor to become a TTE upgrade unit as longevity and performance are paramount. Good balance improves acoustics also. Subsequent great care is taken with all TTE turbochargers to achieving strict balance standards. Firstly parts are balanced at slow speeds up to 2800RPM in multiple planes using a single parts machine, then components are assembled and then the CHRA are dynamically balanced, but this time depending on application at up to 250,000 RPM in multiple planes using a VSR machine to acquire the ultimate equilibrium, to a standard far higher than OEM. Each turbocharger is supplied with a serial numbered balance test result document.

Fitment:

• Porsche 993
• Porsche 996
